Exploring Spandrel: Opaque Solutions in Curtain Wall and Storefront Systems
Introduction:
Did you know that Curtain Wall and Storefront systems can have opaque glazing or panel instead of vision glass?
When it comes to curtain wall and storefront systems, architects have the option to incorporate opaque solutions alongside transparent vision glazing. Opaque elements, known as spandrels, serve to conceal unappealing building components, house mechanical equipment, or reduce solar exposure. This informative guide explores the various types and applications of spandrels, providing architects with insights into design considerations for integrating opaque panels or glazing into their building designs. By collaborating with curtain wall and storefront manufacturers, architects can select the ideal products for their projects, achieving both aesthetic and functional goals.
Understanding Spandrels: Spandrels serve as a non-transparent alternative to vision glazing, effectively concealing unattractive building components such as mechanical, electrical, and plumbing equipment located above ceilings. They can also be utilized for aesthetic purposes or to minimize solar exposure.
Spandrel type and application: When designing a spandrel, it's essential to consider the different types and applications available.
Spandrel solutions can easily fit into standard glazing pockets. One common type is to use an opaque panel, usually made of aluminum, with insulation located bound to it.
There are two types of glazing options available. The first one is Monolithic Glass Spandrel, which is a single pane with an opaque coating on the back that requires insulation behind the glass. The second option is an Insulated Glazing Unit (IGU) Spandrel with an opaque coating on the back, or interlayer within the IGU makeup.
One of the types of spandrel is the Shadow Box Spandrel, which includes transparent IGU vision glass without any coating. The vision is blocked by the backing system that consists of a back pan and insulation. A back pan can be given a color or texture and is set back from the glazing, giving a different aesthetic.
Conclusion:
Architects can enhance the versatility and visual appeal of their designs by utilizing opaque solutions in curtain walls and storefront systems. Spandrels provide a means to conceal unattractive building components, accommodate mechanical equipment, or regulate solar exposure. Achieving the desired aesthetic and functional results entails comprehending the various spandrel types, design considerations, and collaboration with manufacturers.
