Did you know there is an exterior wall assembly that provides an air layer behind its finish layer? A rainscreen is an exterior wall assembly that separates the finish layer from the moisture prevention and thermal layers with a continuous airspace.
A rainscreen system stands off from the building structure using a dedicated sub-framing system or conventional furring methods with metal or wood. This sub-framing creates a continuous air layer behind the finish to support ventilation and drainage.
The air layer behind a rainscreen finish allows water that penetrates the exterior surface to drain and dry efficiently. Proper airflow prevents moisture buildup and supports drying within the wall assembly.
This drainage and ventilation strategy is central to the performance of rainscreen systems across different climates.
It is essential to consider all water entry and exit points in a rainscreen assembly. Proper flashing must be detailed to direct water back out and away from the building.
Trapping water within a rainscreen system defeats its purpose and can cause damage to wall components and finishes.
When designing a rainscreen, all components behind the finish layer must be protected from air, water, and vapor infiltration. The performance of selected products and installation methods directly determines the effectiveness of the system.
Consulting with manufacturers for project-specific product recommendations is essential, particularly when accounting for climate zone conditions and material compatibility.
For further learning, consult reputable organizations such as:
RAiNA – Rainscreen Association of North America for educational content on rainscreen systems
MCA – Metal Construction Association for educational content on metal construction
A well-designed rainscreen wall assembly improves moisture management, ventilation, and durability when properly detailed and installed.
In summary, effective rainscreen performance depends on continuous airspace, proper flashing, and coordination with manufacturers and industry best practices.
