A curtain wall assembly is a non-structural outer covering of a building’s façade. It typically comprises vertical and horizontal framing elements, glass or other transparent/translucent materials, and infill panels such as aluminum spandrel panels. In architectural design, specifying the right curtain wall assembly requires balancing functionality, aesthetics, and performance.
Clearly define the functional requirements of the curtain wall, such as thermal insulation, acoustic performance, and resistance to wind and water. Depending on the size, location, and type of building, you may need to select the appropriate system. Stick-built or unitized assemblies each offer unique advantages and disadvantages, so choosing the system that best suits your project is essential.
Definition: Stick-built refers to the traditional method of constructing a curtain wall on-site piece by piece, similar to assembling a puzzle. Each component, such as vertical and horizontal mullions (framework) and glazing, is installed individually.
Assembly Process: In stick-built construction, the framing members are installed first, followed by the installation of individual glass or other infill panels. This method allows for flexibility in adapting to on-site conditions and is suitable for projects with complex designs or irregular shapes.
On-Site Assembly: The assembly of the curtain wall takes place at the construction site, requiring skilled labor for precise installation.
Definition: Unitized curtain wall systems are pre-fabricated and pre-assembled off-site into large units or panels. These units typically consist of both the framing and glazing elements and are transported to the construction site as complete modules.
Assembly Process: In a controlled factory environment, the curtain wall assembly is completed with higher precision and quality control. On-site, these pre-assembled units are lifted into place and secured to the structure.
Efficiency and Speed: Unitized systems are chosen for efficiency and faster installation, which often reduces labor and cost.
Sealing and Testing: Unitized assemblies can also provide better sealing capabilities, as joints between units are typically factory sealed. This enhances water and air tightness performance.
Materials: Select aluminum, glass, steel, or composite materials based on durability, aesthetics, and performance.
Energy Efficiency: Use insulated glass units and thermal-break systems to boost overall building performance.
Structural Integrity: Collaborate with structural engineers to ensure the curtain wall supports its own weight and imposed loads.
Water and Air Tightness: Choose systems designed to resist infiltration for occupant comfort.
Compliance with Codes: Ensure curtain wall assemblies meet fire safety, wind resistance, and local code requirements.
Cost Considerations: Evaluate how material and system choices affect budgets.
Coordination with Other Systems: Align with HVAC, lighting, and electrical systems for seamless integration.
Testing and Certification: Specify systems that are tested and certified for performance and safety.
Glazing Selection: Select glazing appropriate for climate—low-e glass in hot regions or insulated glass with low solar gain in cold climates.
Always Design Together with your building envelope consultant and product manufacturers to determine which curtain wall assembly is optimal for your project conditions.
A curtain wall assembly is a critical element in modern architecture, balancing performance, aesthetics, and energy efficiency. By carefully evaluating system type, materials, and compliance standards, architects can ensure structural reliability and occupant comfort. Collaboration with engineers and consultants is essential for selecting and implementing the right curtain wall assembly for each project.
